AiP74HC4097

The AiP74HC4051 is a single-pole octal-throw analog switch (SP8T) suitable for use in analog or digital 8:1 multiplexer/demultiplexer applications. The switch features three digital select inputs (S0, S1and S2), eight independent inputs/outputs (Yn), a common input/output (Z) and a digital enable input (E—).

The AiP74HCT4051 is a single-pole octal-throw analog switch (SP8T) suitable for use in analog or digital 8:1 multiplexer/demultiplexer applications. The switch features three digital select inputs (S0, S1and S2), eight independent inputs/outputs (Yn), a common input/output (Z) and a digital enable input (E—).

The AiP74HC4052 is a dual single-pole quad-throw analog switch (2×SP4T)suitable for use in analog or digital 4:1 multiplexer/demultiplexer applications. Each switch features four independent inputs/outputs (nY0, nY1, nY2 and nY3) and a common input/output (nZ). A digital enable input (E—) and two digital select inputs (S0 and S1) are common to both switches.

The AiP74HCT4052 is a dual single-pole quad-throw analog switch (2×SP4T)suitable for use in analog or digital 4:1 multiplexer/demultiplexer applications. Each switch features four independent inputs/outputs (nY0, nY1, nY2 and nY3) and a common input/output (nZ). A digital enable input (E—) and two digital select inputs (S0 and S1) are common to both switches.

The AiP74HC4053 is a triple single-pole double-throw analog switch (3×SPDT) suitable for use in analog or digital 2:1 multiplexer/demultiplexer applications. Each switch features a digital select input(Sn), two independent inputs/outputs (nY0 and nY1) and a common input/output (nZ).

The AiP74HCT4053 is a triple single-pole double-throw analog switch (3×SPDT) suitable for use in analog or digital 2:1 multiplexer/demultiplexer applications. Each switch features a digital select input(Sn), two independent inputs/outputs (nY0 and nY1) and a common input/output (nZ).

The AiP74HC4066 is a quad single pole, single throw analog switch. Each switch features two input/output terminals (nY and nZ) and an active HIGH enable input (nE). When nE is LOW, the analog switch is turned off.

The AIP74HC/HCT4097 is a differential 8-channel multiplexer having three binary control inputs A0, A1,A2 and an inhibit input (E—). The inputs permit selection of one of eight pairs of switches.
